SiBE28-804 Troubleshooting by Remote Controller Display / LED Display
Troubleshooting 159
5.6 “
A1
” Malfunctioning Indoor PC Board
Remote
Controller
Display
A1
LED indications The table below shows the LED indications.
Error generation The error is generated when the data from the EEPROM is not received correctly.
EEPROM (Electrically Erasable Programmable Read Only Memory): A memory chip that holds
its content without power. It can be erased, either within the computer or externally and usually
requires more voltage for erasure than the common +5 volts used in logic circuits. It functions
like non-volatile RAM, but writing to EEPROM is slower than writing to RAM.
Supposed
Causes
The possible cause is a malfunctioning indoor PC board.
Troubleshooting
Operation HAP (green) HBP (green)
Normal
55
Malfunctioning
54
57
4
—
7
—
Switch the power off
and on again to restart.
The malfunction may be caused by an
external factor, rather than damaged parts.
Locate the cause and correct the situation.
Normal reset?
NO
YES
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Replace
indoor PC board.
