Frequency Regulating Functions SiBE28-804
66 Functional Description
Frequency steps The operating frequency for the sky-air RZQ(S) inverter units will be a value chosen from a list
with fixed frequency settings that is programmed in the unit's memory:
: Maximum frequency in cooling
Maximum frequency in RZQ/RZQS71
Step No.
Compressor operation frequency
RZQ71C7,
RZQS71·100C7
RZQ100~140C7
RZQS125·140C7
1 48 Hz 32 Hz
2 52.5 Hz 36 Hz
3 57 Hz 41 Hz
4 61.5 Hz 44 Hz
5 66 Hz 48 Hz
6 72 Hz 52 Hz
7 78 Hz 57 Hz
8 85.5 Hz 62 Hz
9 93 Hz 67 Hz
10 100.5 Hz 72 Hz
11 109.5 Hz 78 Hz
12 118.5 Hz 84 Hz
13 127.5 Hz 90 Hz
14 136.5 Hz 94 Hz
15 145.5 Hz 98 Hz
16 154.5 Hz 102 Hz
17 163.5 Hz 107 Hz
18 174 Hz 112 Hz
19 183 Hz 117 Hz
20 192 Hz 123 Hz
21 201 Hz 131 Hz
22 211.5 Hz 139 Hz
23 222 Hz 147 Hz
24 232.5 Hz 155 Hz
25 243 Hz 164 Hz
26 253.5 Hz —
27 265.5 Hz —
