Specifications SiBE28-804
16 Specifications
1.2.2 Electrical Specifications
The table below contains the electrical specifications.
1.2.3 Electrical Data
Specification RZQS71C7V1B RZQS100C7V1B RZQS125C7V1B RZQS140C7V1B
Power supply
Name V1B
Phase 1~
Frequency 50 Hz
Voltage 220-240 V
Current
Zmax. List Complies to EN61000-3-11
Recommended fuses 20 A 32 A
Voltage range
Mininum 198 V 207 V
Maximum 264 V 253 V
Wire connections
For power supply - remark See installation manual 4PW40416-1 See installation manual 4PW34874-1
For connection with indoor - remark See installation manual 4PW40416-1 See installation manual 4PW34874-1
Power supply intake Outdoor unit only
Notes See separate drawing for electrical data.
See separate drawing for
electrical data.
Power supply intake for
FDQ is outdoor and
indoor unit.
See separate drawing for
electrical data.
Unit combination Power supply Compressor OFM IFM
Indoor unit Outdoor unit Hz-Volts Voltage range MCA TOCA MFA MSC RLA kW FLA kW FLA
FCQH71C7V3B RZQS71C7V1B
50-220
50-230
50-240
Max.50Hz264V
Min.50Hz198V
17.0 17.0 20 16.2 16.2 0.07 0.3 0.120 0.5
FCQ71C7V3B RZQS71C7V1B 17.0 17.0 20 16.2 16.2 0.07 0.3 0.056 0.5
FCQ35C7V3B×2 RZQS71C7V1B 17.1 17.1 20 16.2 16.2 0.07 0.3 0.056×2 0.3×2
FFQ35BV1B×2 RZQS71C7V1B 17.7 17.7 20 16.2 16.2 0.07 0.3 0.055×2 0.6×2
FBQ71B7V3B RZQS71C7V1B 17.4 17.4 20 16.2 16.2 0.07 0.3 0.125 0.9
FBQ35B7V1×2 RZQS71C7V1B 17.5 17.5 20 16.2 16.2 0.07 0.3 0.065×2 0.5×2
FHQ71BUV1B RZQS71C7V1B 17.1 17.1 20 16.2 16.2 0.07 0.3 0.062 0.6
FHQ35BUV1B×2 RZQS71C7V1B 17.7 17.7 20 16.2 16.2 0.07 0.3 0.062×2 0.6×2
FAQ71BUV1B RZQS71C7V1B 16.8 16.8 20 16.2 16.2 0.07 0.3 0.043 0.3
FVQ71BV1B RZQS71C7V1B 17.3 17.3 20 16.2 16.2 0.07 0.3 0.175 0.8
FCQH100C7V3B RZQS100C7V1B
50-220
50-230
50-240
Max.50Hz264V
Min.50Hz198V
19.4 19.4 20 17.7 17.7 0.07 0.3 0.120 1.4
FCQ100C7V3B RZQS100C7V1B 18.7 18.7 20 17.7 17.7 0.07 0.3 0.120 0.7
FCQ50C7V3B×2 RZQS100C7V1B 18.6 18.6 20 17.7 17.7 0.07 0.3 0.056×2 0.3×2
FCQ35C7V3B×3 RZQS100C7V1B 18.9 18.9 20 17.7 17.7 0.07 0.3 0.056×2 0.3×3
FFQ50BV1B×2 RZQS100C7V1B 19.4 19.4 20 17.7 17.7 0.07 0.3 0.055×2 0.7×2
FFQ35BV1B×3 RZQS100C7V1B 19.8 19.8 20 17.7 17.7 0.07 0.3 0.055×3 0.6×3
FBQ100B7V3B RZQS100C7V1B 19.0 19.0 20 17.7 17.7 0.07 0.3 0.135 1.0
FBQ50B7V1×2 RZQS100C7V1B 19.4 19.4 20 17.7 17.7 0.07 0.3 0.085×2 0.7×2
FBQ35B7V1×3 RZQS100C7V1B 19.5 19.5 20 17.7 17.7 0.07 0.3 0.065×3 0.5×3
FHQ100BUV1B RZQS100C7V1B 18.7 18.7 20 17.7 17.7 0.07 0.3 0.130 0.7
FHQ50BUV1B×2 RZQS100C7V1B 19.2 19.2 20 17.7 17.7 0.07 0.3 0.062×2 0.6×2
FHQ35BUV1B×3 RZQS100C7V1B 19.8 19.8 20 17.7 17.7 0.07 0.3 0.062×3 0.6×3
FAQ100BUV1B RZQS100C7V1B 18.4 18.4 20 17.7 17.7 0.07 0.3 0.049 0.4
FVQ100BV1B RZQS100C7V1B 19.4 19.4 20 17.7 17.7 0.07 0.3 0.320 1.4
FCQH125C7V3B RZQS125C7V1B
50-220
50-230
50-240
Max.50Hz264V
Min.50Hz198V
25.4 25.4 32 23.4 23.4
0.07+0.07
0.3+0.3 0.120 1.4
FCQ125C7V3B RZQS125C7V1B 25.0 25.0 32 23.4 23.4
0.07+0.07
0.3+0.3 0.120 1.0
FCQ60C7V3B×2 RZQS125C7V1B 24.8 24.8 32 23.4 23.4
0.07+0.07
0.3+0.3 0.056×2 0.4×2
FCQ50C7V3B×3 RZQS125C7V1B 24.9 24.9 32 23.4 23.4
0.07+0.07
0.3+0.3 0.056×3 0.3×3
FCQ35C7V3B×4 RZQS125C7V1B 25.2 25.2 32 23.4 23.4
0.07+0.07
0.3+0.3 0.056×4 0.3×4
FFQ60BV1B×2 RZQS125C7V1B 25.4 25.4 32 23.4 23.4
0.07+0.07
0.3+0.3 0.055×2 0.7×2
FFQ50BV1B×3 RZQS125C7V1B 26.1 26.1 32 23.4 23.4
0.07+0.07
0.3+0.3 0.055×3 0.7×3
FFQ35BV1B×4 RZQS125C7V1B 26.4 26.4 32 23.4 23.4
0.07+0.07
0.3+0.3 0.055×4 0.6×4
FBQ125B7V3B RZQS125C7V1B 25.4 25.4 32 23.4 23.4
0.07+0.07
0.3+0.3 0.225 1.4
FBQ60B7V1×2 RZQS125C7V1B 25.8 25.8 32 23.4 23.4
0.07+0.07
0.3+0.3 0.125×2 0.9×2
FBQ50B7V1×3 RZQS125C7V1B 26.1 26.1 32 23.4 23.4
0.07+0.07
0.3+0.3 0.085×3 0.7×3
FBQ35B7V1×4 RZQS125C7V1B 26.0 26.0 32 23.4 23.4
0.07+0.07
0.3+0.3 0.065×4 0.5×4
FHQ125BUV1B RZQS125C7V1B 24.7 24.7 32 23.4 23.4
0.07+0.07
0.3+0.3 0.130 0.7
FHQ60BUV1B×2 RZQS125C7V1B 25.2 25.2 32 23.4 23.4
0.07+0.07
0.3+0.3 0.062×2 0.6×2
FHQ50BUV1B×3 RZQS125C7V1B 25.8 25.8 32 23.4 23.4
0.07+0.07
0.3+0.3 0.062×3 0.6×3
FHQ35BUV1B×4 RZQS125C7V1B 26.4 26.4 32 23.4 23.4
0.07+0.07
0.3+0.3 0.062×4 0.6×4
FDQ125B7V3B RZQS125C7V1B 28.2 28.2 32 23.4 23.4
0.07+0.07
0.3+0.3 0.500 4.2
FVQ125BV1B RZQS125C7V1B 25.6 25.6 32 23.4 23.4
0.07+0.07
0.3+0.3 0.365 1.6
