SiBE28-804 Specifications
Specifications 13
Symbols:
MCA: Min. Circuit Amps
TOCA: Total Over-current Amps
MFA: Max. Fuse Amps (see note 7)
MSC : Max. current during the starting compressor
RLA : Rated Load Amps
OFM : Outdoor Fan Motor
IFM : Indoor Fan Motor
FLA : Full Load Amps
kW : Fan Motor Rated Output
Notes:
1. RLA is based on the following conditions:
Power supply: 50Hz 230V
Indoor temp. - cooling: 27°C DB/19.0°C WB
Indoor temp. - heating: 20.0°C DB
Outdoor temp. - cooling: 35.0°C DB
Outdoor temp. - heating: 7.0°C DB/6.0°C WB
2. TOCA means the total value of each OC set.
3. Voltage range
Units are suitable for use on electrical systems where voltage
supplied to unit terminals is not below or above listed range limits.
4. Maximum allowable voltage variation between phases is 2%.
5. MCA represents maximum input current.
MFA represents capacity which may accept MCA. (Next lower standard fuse rating, minimum 15A)
6. Select wire size based on the larger value of MCA or TOCA.
7. MFA is used to select the circuit breaker and the ground fault circuit interruptor. (earth leakage circuit
breaker)
FCQH140C7V3B RZQ140C7V1B
50-220
50-230
50-240
Max.50Hz264V
Min.50Hz198V
25.4 25.4 32 23.4 23.4
0.07+0.07
0.3+0.3 0.120 1.4
FCQ140C7V3B RZQ140C7V1B 25.0 25.0 32 23.4 23.4
0.07+0.07
0.3+0.3 0.120 1.0
FCQ71C7V3B×2 RZQ140C7V1B 25.0 25.0 32 23.4 23.4
0.07+0.07
0.3+0.3 0.056×2 0.5×2
FCQ50V7V3B×3 RZQ140C7V1B 24.9 24.9 32 23.4 23.4
0.07+0.07
0.3+0.3 0.056×3 0.3×3
FCQ35C7V3B×4 RZQ140C7V1B 25.2 25.2 32 23.4 23.4
0.07+0.07
0.3+0.3 0.056×4 0.3×4
FFQ50BV1B×3 RZQ140C7V1B 26.1 26.1 32 23.4 23.4
0.07+0.07
0.3+0.3 0.055×3 0.7×3
FFQ35BV1B×4 RZQ140C7V1B 26.4 26.4 32 23.4 23.4
0.07+0.07
0.3+0.3 0.055×4 0.6×4
FBQ71B7V3B×2 RZQ140C7V1B 25.8 25.8 32 23.4 23.4
0.07+0.07
0.3+0.3 0.125×2 0.9×2
FBQ50B7V1×3 RZQ140C7V1B 26.1 26.1 32 23.4 23.4
0.07+0.07
0.3+0.3 0.085×3 0.7×3
FBQ35B7V1×4 RZQ140C7V1B 26.0 26.0 32 23.4 23.4
0.07+0.07
0.3+0.3 0.065×4 0.5×4
FHQ71BUV1B×2 RZQ140C7V1B 25.2 25.2 32 23.4 23.4
0.07+0.07
0.3+0.3 0.062×2 0.6×2
FHQ50BUV1B×3 RZQ140C7V1B 25.8 25.8 32 23.4 23.4
0.07+0.07
0.3+0.3 0.062×3 0.6×3
FHQ35BUV1B×4 RZQ140C7V1B 26.4 26.4 32 23.4 23.4
0.07+0.07
0.3+0.3 0.062×4 0.6×4
FAQ71BUV1B×2 RZQ140C7V1B 24.6 24.6 32 23.4 23.4
0.07+0.07
0.3+0.3 0.043×2 0.3×2
FUQ71BUV1B×2 RZQ140C7V1B 25.4 25.4 32 23.4 23.4
0.07+0.07
0.3+0.3 0.045×2 0.7×2
Unit combination Power supply Compressor OFM IFM
Indoor unit Outdoor unit Hz-Volts Voltage range MCA TOCA MFA MSC RLA kW FLA kW FLA
