Specifications SiBE28-804
12 Specifications
1.1.2 Electrical Specifications
The table below contains the electrical specifications.
Notes:
*1 Separate power supply is needed for FDQ indoor unit.
1.1.3 Electrical Data
Specification RZQ71C7V1B RZQ100C7V1B RZQ125C7V1B RZQ140C7V1B
Power supply
Name V1B
Phase 1~
Frequency 50 Hz
Voltage 230 V
Current
Zmax. List Complies to EN61000-3-11
Recommended fuses 20 A 32 A
Voltage range
Mininum 198 V 207 V
Maximum 264 V 253 V
Wire connections
For power supply - remark
See installation manual
4PW40417-1
See installation manual 4PW34874-1
For connection with indoor - remark
See installation manual
4PW40417-1
See installation manual 4PW34874-1
Power supply intake Outdoor unit only
Notes
See separate drawing for
electrical data.
See separate drawing for electrical data. *1
Unit combination Power supply Compressor OFM IFM
Indoor unit Outdoor unit Hz-Volts Voltage range MCA TOCA MFA MSC RLA kW FLA kW FLA
FCQH71C7V3B RZQ71C7V1B
50-220
50-230
50-240
Max. 50Hz 264V
Min. 50Hz 198V
17.0 17.0 20 16.2 16.2 0.07 0.3 0.120 0.5
FCQ71C7V3B RZQ71C7V1B 17.0 17.0 20 16.2 16.2 0.07 0.3 0.056 0.5
FCQ35C7V3B×2 RZQ71C7V1B 17.1 17.1 20 16.2 16.2 0.07 0.3 0.056×2 0.3×2
FFQ35BV1B×2 RZQ71C7V1B 17.7 17.7 20 16.2 16.2 0.07 0.3 0.055×2 0.6×2
FBQ71B7V3B RZQ71C7V1B 17.4 17.4 20 16.2 16.2 0.07 0.3 0.125 0.9
FBQ35B7V1×2 RZQ71C7V1B 17.5 17.5 20 16.2 16.2 0.07 0.3 0.065×2 0.5×2
FHQ71BUV1B RZQ71C7V1B 17.1 17.1 20 16.2 16.2 0.07 0.3 0.062 0.6
FHQ35BUV1B×2 RZQ71C7V1B 17.7 17.7 20 16.2 16.2 0.07 0.3 0.062×2 0.6×2
FAQ71BUV1B RZQ71C7V1B 16.8 16.8 20 16.2 16.2 0.07 0.3 0.043 0.3
FUQ71BUV1B RZQ71C7V1B 17.2 17.2 20 16.2 16.2 0.07 0.3 0.045 0.7
FCQH100C7V3B RZQ100C7V1B
50-220
50-230
50-240
Max. 50Hz 264V
Min. 50Hz 198V
25.4 25.4 32 23.4 23.4
0.07+0.07
0.3+0.3 0.120 1.4
FCQ100C7V3B RZQ100C7V1B 24.7 24.7 32 23.4 23.4
0.07+0.07
0.3+0.3 0.120 0.7
FCQ50C7V3B×2 RZQ100C7V1B 24.6 24.6 32 23.4 23.4
0.07+0.07
0.3+0.3 0.056×2 0.3×2
FCQ35C7V3B×3 RZQ100C7V1B 24.9 24.9 32 23.4 23.4
0.07+0.07
0.3+0.3 0.056×3 0.3×3
FFQ50BV1B×2 RZQ100C7V1B 25.4 25.4 32 23.4 23.4
0.07+0.07
0.3+0.3 0.055×2 0.7×2
FFQ35BV1B×3 RZQ100C7V1B 25.8 25.8 32 23.4 23.4
0.07+0.07
0.3+0.3 0.055×3 0.6×3
FBQ100B7V3B RZQ100C7V1B 25.0 25.0 32 23.4 23.4
0.07+0.07
0.3+0.3 0.135 1.0
FBQ50B7V1×2 RZQ100C7V1B 25.4 25.4 32 23.4 23.4
0.07+0.07
0.3+0.3 0.085×2 0.7×2
FBQ35B7V1×3 RZQ100C7V1B 25.5 25.5 32 23.4 23.4
0.07+0.07
0.3+0.3 0.065×3 0.5×3
FHQ100BUV1B RZQ100C7V1B 24.7 24.7 32 23.4 23.4
0.07+0.07
0.3+0.3 0.130 0.7
FHQ50BUV1B×2 RZQ100C7V1B 25.2 25.2 32 23.4 23.4
0.07+0.07
0.3+0.3 0.062×2 0.6×2
FHQ35BUV1B×3 RZQ100C7V1B 25.8 25.8 32 23.4 23.4
0.07+0.07
0.3+0.3 0.062×3 0.6×3
FAQ100BUV1B RZQ100C7V1B 24.4 24.4 32 23.4 23.4
0.07+0.07
0.3+0.3 0.049 0.4
FUQ100BUV1B RZQ100C7V1B 25.1 25.1 32 23.4 23.4
0.07+0.07
0.3+0.3 0.090 1.1
FCQH125C7V3B RZQ125C7V1B
50-220
50-230
50-240
Max.50Hz264V
Min.50Hz198V
25.4 25.4 32 23.4 23.4
0.07+0.07
0.3+0.3 0.120 1.4
FCQ125C7V3B RZQ125C7V1B 25.0 25.0 32 23.4 23.4
0.07+0.07
0.3+0.3 0.120 1.0
FCQ60C7V3B×2 RZQ125C7V1B 24.8 24.8 32 23.4 23.4
0.07+0.07
0.3+0.3 0.056×2 0.4×2
FCQ50C7V3B×3 RZQ125C7V1B 24.9 24.9 32 23.4 23.4
0.07+0.07
0.3+0.3 0.056×3 0.3×3
FCQ35C7V3B×4 RZQ125C7V1B 25.2 25.2 32 23.4 23.4
0.07+0.07
0.3+0.3 0.056×4 0.3×4
FFQ60BV1B×2 RZQ125C7V1B 25.4 25.4 32 23.4 23.4
0.07+0.07
0.3+0.3 0.055×2 0.7×2
FFQ50BV1B×3 RZQ125C7V1B 26.1 26.1 32 23.4 23.4
0.07+0.07
0.3+0.3 0.055×3 0.7×3
FFQ35BV1B×4 RZQ125C7V1B 26.4 26.4 32 23.4 23.4
0.07+0.07
0.3+0.3 0.055×4 0.6×4
FBQ125B7V3B RZQ125C7V1B 25.4 25.4 32 23.4 23.4
0.07+0.07
0.3+0.3 0.225 1.4
FBQ60B7V1×2 RZQ125C7V1B 25.8 25.8 32 23.4 23.4
0.07+0.07
0.3+0.3 0.125×2 0.9×2
FBQ50B7V1×3 RZQ125C7V1B 26.1 26.1 32 23.4 23.4
0.07+0.07
0.3+0.3 0.085×3 0.7×3
FBQ35B7V1×4 RZQ125C7V1B 26.0 26.0 32 23.4 23.4
0.07+0.07
0.3+0.3 0.065×4 0.5×4
FHQ125BUV1B RZQ125C7V1B 24.7 24.7 32 23.4 23.4
0.07+0.07
0.3+0.3 0.130 0.7
FHQ60BUV1B×2 RZQ125C7V1B 25.2 25.2 32 23.4 23.4
0.07+0.07
0.3+0.3 0.062×2 0.6×2
FHQ50BUV1B×3 RZQ125C7V1B 25.8 25.8 32 23.4 23.4
0.07+0.07
0.3+0.3 0.062×3 0.6×3
FHQ35BUV1B×4 RZQ125C7V1B 26.4 26.4 32 23.4 23.4
0.07+0.07
0.3+0.3 0.062×4 0.6×4
FUQ125BUV1B RZQ125C7V1B 25.1 25.1 32 23.4 23.4
0.07+0.07
0.3+0.3 0.090 1.1
FDQ125B7V3B RZQ125C7V1B 28.2 28.2 32 23.4 23.4
0.07+0.07
0.3+0.3 0.500 4.2
