SiBE28-804 Troubleshooting by Remote Controller Display / LED Display
Troubleshooting 203
5.31 “
L8
” Electronic Thermal (Time Lag)
Remote
Controller
Display
L8
Applicable
Models
RZQ(S)71~140
Method of
Malfunction
Detection
Malfunction is detected by converting the current flowing to power transistor into voltage with
CT1 (DC current sensor).
Inverter PC board detects the disorder of position signal.
Malfunction
Decision
Conditions
When compressor overload (except for when startup) is detected.
Supposed
Causes
Compressor overload (during operation)
Disconnected compressor coil
Faulty inverter
Faulty compressor (if bearing is scratched)
