56 / 322
(1) Block: if the port of unicast, multicast or broadcast in a message flow is greater than the
upper threshold, the port will suspend forwarding the packets (other types of packet forwarding, as
usual) port in the blocking state, but the port is still statistics of the kind of message flow。When
this kind of message traffic is less than the lower threshold, the port will resume the forwarding of
this kind of message。
(2)
Shutdown mode: if a class of unicast, multicast or broadcast on the port is larger than the
upper limit, the port will be closed, and the system will stop forwarding all packets。The port state
can be restored by executing the undo shutdown command, and it can also be restored by
canceling the port traffic threshold configuration。
Note: for a certain type of message traffic, it can be suppressed by the function or the storm
suppression function of the Ethernet port, but the two functions can not be configured at the same
time, otherwise the suppression effect is uncertain。For example, the unicast traffic threshold
control function and unicast storm suppression function can not be configured at the same time。
The CLI configuration commands are as follows：
command
describe
CLI mode
storm-constrain
(broadcast|multicast|unicast) min-rate
<1-1488100> max-rate <1-1488100>
Storm control for
broadcast, multicast, or
unknown unicast messages
under the interface
Interface
configuration mode
no storm-constrain
(broadcast|multicast|unicast|all)
Cancel storm control
Interface
configuration mode
storm-constrain action (block|shutdown)
Configure storm control
actions and, without default,
storm control for messages
Interface
configuration mode
no storm-constrain action
Cancel the configured
storm control action
Interface
configuration mode
storm-constrain enable (log|trap)
Switch to record or report
alarm when storm control is
opened
Interface
configuration mode
no storm-constrain enable (log|trap|all)
Switch to log or report
alarm when storm control is
closed
Interface
configuration mode
storm-constrain interval <6-180>
Configure the storm
control detection interval, by
default, the storm control
Interface
configuration mode
