Aten EC1000 [10/81] Conventions

EC1000 User Manual

Conventions

This manual uses the following conventions:

Monospaced Indicates text that you should key in.

[ ] Indicates keys you should press. For example, [Enter] means

to press the Enter key. If keys need to be chorded, they appear

together in the same bracket with a plus sign between them:

[Ctrl+Alt].

1. Numbered lists represent procedures with sequential steps.

♦ Bullet lists provide information, but do not involve sequential

steps.

Indicates selecting the option (on a menu or dialog box, for

example), that comes next. For example, Start

Run means to

open the Start menu, and then select Run.

Indicates critical information.
