Aten EC1000 [49/81] Security

Chapter 4. Browser Operation

Security

The Security page controls access to the EC1000.

 Allowed sets the number of consecutive failed login attempts that are

permitted from a remote user.

 Timeout sets the amount of time a remote user must wait before

attempting to login again after exceeding the number of allowed failures.

Working Mode

 If ICMP is enabled, the EC1000 Energy Box can be pinged. If it is not

enabled, the device cannot be pinged. The default is Enabled.

Session Timeout

 Check to enable/disable web session timeout. When enabled, enter a

number in the minute field.

When enabled, current web sessions will timeout if left idle for the entered

time.
