Aten EC1000 [14/81] Requirements

EC1000 User Manual

Requirements

 Energy PDU PE1216, PE1324, PE2220, or PE2340

 Environmental Sensors EA1140, EA1240, EA1340 to monitor

environmental data

 One Cat 5e Ethernet cable to connect the EC1000 to the local area network

 Browsers accessing the EC1000 must support SSL 128 bit encryption.
