EC1000 User Manual
22
Browser Operation
First Time Setup
Once the Energy Box installation has been cabled up, the next task the
administrator needs to perform involves configuring the network parameters,
changing the default administrator login settings, and adding users.
To accomplish this you must login over the network with a browser
(See Browser Login, page 20, for details).
Note: 1. Since this is the first time you are logging in, use the default
username: administrator; and the default password: password. For
security purposes we recommend changing them to something unique
(see Changing the Administrator Login, page 24).
2. For remote methods of getting logged in, use the Select button from
the front panel of the EC1000 to obtain the IP address and enter it into
a web browser to access the Energy Box; or see IP Address
Determination, page 68.
After you successfully log in, the Access/Connections page appears:
Note: Operation details are discussed in Access, page 25.
