Chapter 1. Introduction
5
Optional Accessories
Sensors
Sensors are optional accessories. You can use the EC1000 Energy Box without
sensors. However, if you want to have complete energy management of your
data center with the full use of the EC1000 Energy Box, you would need to use
eco DC (Energy & DCIM Management Web GUI) and install 4 sensors for
each of the racks to generate more complete energy-efficient data and charts.
Sensors help you maintain a safe and highly efficient data center by monitoring
environmental conditions. Higher sensor density installations help to generate
more accurate and precise data. Available sensors are show in the table, below:
Sensor Management
Sensors can be managed via the EC1000’s browser based graphical user
interface (GUI) or with ATEN eco DC that can be downloaded from the ATEN
website.
Sensor Part Number
Temperature EA1140
Temperature / Humidity EA1240
Differential Pressure / Temperature EA1340
