Aten EC1000 [79/81] Method 2

Appendix

2. If there is more than one device in the list, use the MAC address

to pick the one you want. The eco PDU's MAC address is located

on its bottom panel.

4. Select either Obtain an IP address automatically (DHCP), or Specify an

IP address. If you chose the latter, fill the IP Address, Subnet Mask, and

Gateway fields with the information appropriate to your network.

5. Click Set IP.

6. After the IP address shows up in the Device List, click Exit to end the

program.

Method 2:

1. Set your computer's IP address to 192.168.0.XXX

Where XXX represents any number or numbers except 60. (192.168.0.60) is

the default address of the Energy Box.)

2. Specify the device’s default IP address (192.168.0.60) in your browser,

and you will be able to connect.

3. Assign a fixed IP address for the device (see IPv4 Configuration, page 36),

that is suitable for the network segment that it resides on.

4. After you log out, reset your computer's IP address to its original value.

5. Once you have logged in, go to Network Settings to set up the permanent

IP environment (see IPv4 Configuration, page 36).

Method 3:

ATEN eco DC allows you to determine/assign an IP address in order to

configure a Energy Box and monitor power status of the equipment connected

to it. ATEN eco DC can be obtained from the Download area of the ATEN

website.
