EC1000 User Manual
2
Features
Operation
Space saving 1U and 0U rack mounting with front, rear, and side mounting
4 RJ-45 Energy Sensor Ports to monitor four Energy PDUs (0A to 32A per
port) electrical currents
4 RJ-11 Environmental Sensor Ports to monitor temperature, humidity,
and differential pressure*
Maximum Amperage Monitor 32A@100V~240V (Energy Box)
3 digit 7 segment front panel LED displays current/sensor/IP address
information
Threshold monitoring for:
Current
Temperature*
Humidity*
Differential pressure*
Threshold alerting through:
Local: audible alarm and LED lights
Remote: SMTP/SNMP trap/Syslog
Management
Front panel LED indicators for current, temperature*, humidity*,
differential pressure*, and IP address at the Energy Box
Remote real-time current, temperature*, humidity*, and differential
pressure* monitoring and management
Management through eco DC Energy & DCIM Management Web GUI or
3rd party SNMP manager
Supports name assignment for individual Energy PDUs
Multi-language GUI supports: English, Traditional Chinese, Simplified
Chinese, Japanese, Korean, German, Italian, Spanish, Portuguese, French,
Russian
Event Logging – 128 line event log
Syslog support
F/W upgradable
