EC1000 User Manual

Administrator Login Failure

If you are unable to perform an administrator login (because the username and

password information has become corrupted, or you have forgotten it, for

example), you can clear the login information with the following procedure:

1. Power off the Energy Box and remove its housing.

2. Short the jumper labeled J6.

3. Power on the Energy Box.

4. After the Energy Box beeps (6 seconds), power off the switch.

5. Remove the jumper cap from J6.

6. Close the housing and start the Energy Box.

After you start, you can use the default username and password to log in.
