Aten EC1000 [35/81] Access

Chapter 4. Browser Operation

Access

Connections

When you login to the EC1000, the interface opens with its default selection of

the Connections menu of the Access tab. The contents of the Energy Sensor

Status and Monitor Status sections are displayed in the main panel.
