Aten EC1000 [13/81] Remote access

Chapter 1. Introduction

Remote Access

 Remote management via TCP/IP using built in 10/100Mbps Ethernet port

 Management via built in browser based GUI

 Network Interfaces: TCP/IP, UDP, HTTP, HTTPS, SSL, SMTP, DHCP,

NTP, DNS, 10Base-T/100Base-TX, auto sense, Ping

 Supports SNMP Manager V1, V2, V3

Security

 Strong security features include password protection and advanced

encryption technologies – TLS1.2

 RADIUS authorization and authentication

*Requires external sensors (see Optional Accessories, page 5).
