Aten EC1000 [17/81] Ec1000 rear view

Chapter 1. Introduction

EC1000 Rear View

*External sensors are sold separately (see Optional Accessories, page 5).

6 Power LED Lights (Green) when the Energy Box is powered up and

ready to operate.

No. Component Description

1 Grounding Terminal The wire used to ground the Energy Box attaches here.

2 Energy Sensor Ports The four RJ-45 cables that connect the Energy Box to

your Energy PDUs, plug in here.

3 Environmental Sensor

Ports

External sensors plug into these four RJ-11 ports.*

4 Power Jack The power adapter cable plugs into this jack.

5 LAN Port The cable that connects the Energy Box to the LAN

plugs in here.

No. Component Description
