Aten EC1000 [44/81] General

EC1000 User Manual

Setup

The Setup page allows administrators to configure and control overall EC1000

operations.

Device Configuration

This page provides information about the EC1000, as described in the

following sections:

General

Item Meaning

Energy Box Name This field lets you give the device a unique name. Simply delete

whatever is in the text box and key in the name of your choice.

Click Save (located at the bottom of the page) to save the new

name.
