Chapter 4. Browser Operation
31
Log
The EC1000 keeps a record of transactions that take place on its installation,
and stores up to 128 events at one time. The System Log page (selected in the
menu bar) provides functions that allow you to view and export the log file
data. If you need to log more then 128 events at a time, a syslog server can be
used (see Syslog Server, page 49).
The Notification Settings page (selected in the menu bar) allows you to setup
email notifications of specified events as they occur.
The System Log
Clicking on a device in the Sidebar displays its log events in the main
panel’s log event list.
Clicking the Refresh button brings the log list up to date with the latest
events.
The entry box to the right of the Refresh button lets you set the number of
events to display per page. Simply key in the number of your choice.
The top right of the main panel shows the total number of pages in the log
file, and what page you are currently viewing.
The buttons on the bottom row function as follows:
Clear – click to erase the contents of the log event list
First Page – click to go to the first page of the log event list
