EC1000 User Manual

 Previous Page – click to move to the previous page of the log event

list

 Next Page – click to move to the next page of the log event list

 Last Page – click to move to the last page of the log event list

 Save – click to save the contents of the log event list to a Csv or Txt

type file.
