EC1000 User Manual
30
4. Set the sensor-by-sensor permissions of the user in the Energy Sensor
field.
5. Click Save to save your settings.
Note: Correct values must be entered in both the Name and Password
fields to enable an account. For account policies see page 40.
The various options are explained in more detail in the following table:
Field Description
Management The Management field allows you to Enable or Disable a
user’s account:
Enable – stores the user account
Disable – disables the user account
Name 1 to 16 characters are allowed depending on the Account
Policy settings. See Account Policy, page 40.
Password 1 to 16 characters are allowed depending on the Account
Policy settings. See Account Policy, page 40.
Energy Sensor This field allows you to set the Energy sensor-by-sensor
permissions of the user. Click on the user/port icon to cycle
through the three permissions options as follows:
User has complete access to this sensor port.
User has read-only access to this sensor port.
User has no access to this sensor port.
