Chapter 2. Hardware Setup
13
Installation
To set up your EC1000 Energy Box installation, refer to the installation
diagram on the next page (the numbers in the diagram correspond to the
numbered steps), and do the following:
1. Use a grounding wire to ground the Energy Box by connecting one end of
the wire to its grounding terminal, and the other end of the wire to a
suitable grounded object.
Note: Do not omit this step. Proper grounding helps to prevent damage to
the unit from surges or static electricity.
2. For each Energy PDU you want to connect, use an RJ-45 cable included
with the package to connect the Energy Box to the Energy PDU.
3. Plug the cable that connects the Energy Box to the LAN, into the LAN
port.
4. (Optional) If you are using environmental sensors with your Energy Box
installation, connect them to the rear environmental sensor ports, and see
Securing the Sensors, page 15 for sensor installation.
Note: Sensors are optional. Please see Optional Accessories, page 5.
5. Connect the power adapter to an AC power source.
