EC1000 User Manual
18
Selection
LED
Port
LEDs
Data LED Displays Data LED Description
Energy 1-4 Current Displays the power current of the
Energy PDU connected to Energy
Sensor port 1, 2, 3, or 4.
The data range is 0–20 A.
When an Energy port is selected the
EC1000 displays real-time data for that
port until you manual switch to another
port.
Environment 1-4 Temperature
Humidity
Differential Pressure
Displays the Temperature, Humidity,
and Differential Pressure of the sensor
connected to Environmental Sensor
port 1, 2, 3, or 4.
When an Environmental Sensor port is
selected the Data LED will switch
between the readings, flashing a letter
first to represent the data to be
displayed, then displays the data
reading. The letter and data ranges
are:
(T) Temperature: -20–60ºC
(H) Humidity: 15–95
(D) Differential Pressure: -250–250*
After the environmental data is
displayed, the EC1000 automatically
switches back to Energy Sensor port
1.
*The Differential Pressure only shows
absolute values due to the displays
limitation of 3 digits.
IP 1 IP Address Displays the IP address of the
EC1000, switching between each of
the four octets that make up the full IP
address.
After the IP address is displayed twice,
the EC1000 automatically switches
back to Energy Sensor port 1.
