GRAPHITE 58G492 [15/108] Operation and maintenance

• Tilt the saw so the front edge of the saw footplate (9) rests on the

cut material and 0° marker for perpendicular cutting is in the line

of planned cutting.

• When the saw is in the place to start cutting, lift the lower guard

(13) with the lower guard lever (4) (cutting blade is lifted above

the material).

• Switch the power tool on and wait until cutting blade reaches its

full rotational speed.

• Gradually lower the saw and plunge the cutting blade in material

(during this move front edge of the saw base should have contact

with surface of the material).

• When the blade starts cutting, release the lower guard.

• When whole surface of the saw base rests on the material, move

the saw forward to proceed with cutting.

• Never move the saw backwards when the blade is rotating, there

is danger of kick back.

• Finish cutting in reverse order it was started, by turning the saw

around line of contact of the processed material and the front

edge of the tool base.

• Before removing blade from the material, allow it to stop after

switching the saw oﬀ.

• Finish the corner ﬁllets with reciprocating saw or hand saw when

necessary.

CUTTING OR CUTTING OFF LARGE PIECES OF MATERIAL

When cutting large boards of material support them to avoid

potential blade hitch (kick back) due to pinching the blade in

material kerf.

OPERATION AND MAINTENANCE

Unplug the power cord from the mains socket before commencing

any activities related to installation, adjustment, repair or

maintenance.

MAINTENANCE AND STORAGE

• Cleaning the device after each use is recommended.

• Do not use water or any other liquid for cleaning.

• Clean the tool with a brush or blow through with compressed air

at low pressure.

• Do not use any cleaning agents or solvents, they may damage

plastic parts.

• Clean ventilation holes in the motor casing regularly to prevent

device overheating. Do not clean ventilation holes by inserting

sharp objects there, such as screwdrivers and other similar objects.

• In case of power cord damage replace it with a cord with the same

speciﬁcation. Entrust the repair to a qualiﬁed specialist or return

the tool to a service point.

• In case of excessive commutator sparking, have the technical

condition of carbon brushes of the motor checked by a qualiﬁed

person.

• During normal operation cutting blade gets blunt after some

time. When it happens it is necessary to apply greater pressure

when moving the saw during cutting.

• When cutting blade is found damaged, replace it immediately.

• Cutting blade must always be sharp.

• Always store the tool in a dry place, beyond reach of children.

CUTTING BLADE REPLACEMENT

• Use supplied hexagonal key to unscrew the ﬁxing bolt for cutting

blade (12) by turning it counter-clockwise.

• To prevent rotation of saw spindle, lock the spindle with spindle

lock button (19) when unscrewing the bolt that ﬁxes the cutting

blade (g. E).

• Disassemble outer ﬂange washer (11).

• Use lower guard lever (4) to move lower guard (13) so it hides

maximally in the upper guard (2) (check condition and operation

of the spring that pulls the lower guard at that time).

• Slide the cutting blade (10) out through the slit in the saw base (9).

• Position new cutting blade so blade teeth and arrow on the blade

match direction of the arrow on the upper guard.

• Slide the cutting blade into base slot and install on the spindle so

it is well pressed against surface of the inner ﬂange and centred

when seated on its neck.

• Install inner ﬂange washer (11) and tighten the ﬁxing bolt for

cutting blade (12) by turning it clockwise.

When installing cutting blade observe correct direction of the

teeth. Arrow on the saw body shows direction of spindle rotation.

Be very careful when holding the cutting blade in hand. Use

protective gloves to provide protection for your hands against

sharp teeth of cutting blade.

REPLACEMENT OF CARBON BRUSHES

Immediately replace worn out (shorter than 5 mm), burnt or

cracked motor carbon brushes. Always replace both carbon

brushes at a time.

Entrust replacement of carbon brushes only to a qualied person.

Only original parts should be used.

All defects should be repaired by service workshop authorized by

the manufacturer.

TECHNICAL PARAMETERS

RATED PARAMETERS

Circular Saw

Parameter Value

Supply voltage

230 V AC

Power supply frequency

50 Hz

Rated power

1500 W

No load rotational speed

5800 min

-1

Bevel cutting range

- 45°

Max. outer diameter of cutting blade

185 mm

Inner diameter of cutting blade 20 mm

Maximum cutting

depth

At 90° angle 65 mm

At 45° angle 43 mm

Protection class II

Laser class

Laser power

< 1 mW

Wavelength

λ = 650 nm

Weight

4,3 kg

Year of production

2018

NOISE LEVEL AND VIBRATION PARAMETERS

Noise and vibration information.

Parameters of produced noise level, such as sound pressure level

and sound power level Lw

with measurement uncertainty K

are speciﬁed below in this manual, in compliance with EN 60745-

1:2009+A11.

Vibration values a

and measurement uncertainty K are determined

in accordance with EN 60745-1:2009+A11 and speciﬁed below.

Vibration level speciﬁed below in this manual was measured in

accordance with measurement procedure deﬁned in EN 60745-

1:2009+A11 and can be used to compare power tools. It can also be

used for initial assessment of exposure to vibrations.

Speciﬁed vibration level is representative for main applications

of the power tool. Vibration level may change if the power tool is

used for other purposes, with diﬀerent working tools or will not

be maintained properly. The abovementioned factors may lead to

higher exposure to vibrations during whole working time.
