101
14 OTHER FUNCTIONS
New2001
DD
Digital Code (Digital Code)
☞ This item appears only when entering set mode from digi-
tal modes.
Sets the desired digital code for digital code squelch opera-
tion. Total of 100 codes (00–99) are available. (default: 00)
DD
Digital Monitor (Digital Monitor)
☞ This item appears only when entering set mode from digi-
tal modes.
Sets the desired monitoring mode during digital mode opera-
tion from “DIGITAL” and “ANALOG.” (default: DIGITAL)
Select “ANALOG” when using FM mode for monitoring.
DD
Repeater Tone (Repeater Tone)
☞ This item appears only when entering set mode from FM
mode.
Sets subaudible tone frequency (encoder only) for repeater
operation. Total of 50 tone frequencies (67.0–254.1 Hz) are
available. (default: 88.5 Hz)
DD
CTCSS Tone (CTCSS Tone)
☞ This item appears only when entering set mode from FM
mode.
Sets subaudible tone frequency (both encoder and decoder)
for tone squelch operation. Total of 50 tone frequencies
(67.0–254.1 Hz) are available. (default: 88.5 Hz)
CTCSS
Tone
88.5
Repeater
Tone
88.5
Digital
Monitor
DIGITAL
Digital
Code
00
ID-1_ENG_2.qxd 04.9.22 9:30 Page 101 (1,1)
