OTHER FUNCTIONS
New2001
14
DD
Auto Repeater
(Auto Repeater)
☞ This item appears only when entering set mode from FM
mode.
The auto repeater function automatically turns ON or OFF the
duplex operation with a specified shift direction and tone en-
coder, when the operating frequency falls within or outside of
1282.000–1295.000 MHz range. The offset and repeater tone
frequencies are not changed by the auto repeater function. If
necessary, reset these frequencies
• OFF : The auto repeater function is turned OFF.
• ON1 : Activates for duplex only. (default)
• ON2 : Activates for duplex and tone.
DD
Lock (Available in Set Mode screen only)
Turn the RC-24 lock function ON and OFF.
When “ON” is selected, locks the connected RC-24 key oper-
ation, except [PWR], [ ], [ ], [SQL] and [LOW•3].
(Pushing
[F.INP•L] for 0.5 sec. is possible to release the lock function.)
Auto
Repeater
ON1
U.S.A. version only
