6 CALL SIGN SETTING
New2001
tPush [SQL] several times to select the desired character
group, then rotate [DIAL] to select the desired character.
• AB : Alphabets (A to Z)
• 12 : Numbers (0 to 9)
• _/ : Symbols (space and /)
yPush [TXinh• ] to enter the selected character.
• The cursor move to right automatically.
uRepeat the steps r to y to enter your call sign.
iPush [V/M] to fix the call sign and exit the edit condition.
oPush [CALL] to display the note.
!0Push [V/M] to enter the note edit conditions.
• The 1st digit blinks.
!1Repeat the steps r to i to enter the note.
• Up to 4-digit note can be set.
!2Push [V/M] to fix the note and exit the edit condition.
!3Push [CS••1] to exit call sign select mode.
SçåAAB
/
[V/M]
SMY
1:AAAAAAAA
/
[CALL]
SçåAAB
MY
1:A*******
[TXinh• ]
SçåAAB
MY
1:********
[SQL]
Shows the selected character.
Shows the selected character group.
[DIAL]
