102
14
OTHER FUNCTIONS
14
DD
Scan Resume Timer
(Scan Timer)
Selects scan resume timer from T-15, T-10 (default), T-5 and
P-2.
• SCT-15/10/5 : Scan pauses for 15/10/5 sec., then re-
sumes.
• SCP-2 : Pause on a signal until signal disap-
pears, then resumes 2 sec. after the sig-
nal disappears.
DD
Standby Beep (Standby Beep)
☞ This item appears only when entering set mode from Dig-
ital modes.
Turns the beep emission capability when the communicating
station finishes transmitting or the receive signal disappears.
(default: ON)
DD
Auto Reply (Auto Reply)
☞ This item appears only when entering set mode from Dig-
ital modes.
During Digital mode operation, auto reply function is avail-
able. This function replies to an individual station call even
you are away from the transceiver.
After the manual transmission (pushing [PTT]), the Auto
Reply setting is return to OFF automatically.
(default: OFF)
DD
Auto RxCall Reg. (Auto RxCall Reg.)
☞ This item appears only when entering set mode from Dig-
ital modes.
When an individual station call is received, the calling station
call sign can be stored automatically. The stored call sign can
be re-called when selecting a station or repeater call sign.
(default: OFF)
Auto
RxCall
Reg.
OFF
Auto
Reply
OFF
Standby
Beep
ON
Scan
Timer
T-10
ID-1_ENG_2.qxd 04.9.22 9:30 Page 102 (1,1)
