103
14 OTHER FUNCTIONS
New2001
DD
Auto RxCall Disp (Auto RxCall Disp)
☞ This item appears only when entering set mode from Dig-
ital modes.
When an individual station call is received, the calling station
call sign can be displayed on the RC-24 function display.
(default: ON)
DD
Auto MyCall Disp (Auto MyCall Disp)
☞ This item appears only when entering set mode from Dig-
ital modes.
When operating in a Digital mode, your programmed call sign
can be displayed on the RC-24 function display during trans-
mit. (default: ON)
DD
(Extension: Available in RC-24 only)
This item turn expanded set mode ON and OFF.
The expanded set mode includes infrequently changed val-
ues or conditions of functions. When OFF (default) is se-
lected, the following 4 items, key touch beep, dimmer, cooling
fan and auto repeater, are hidden.
DD
Key touch beep (Beep)
The key-touch beep for the RC-24 can be turned OFF for
silent operation. (default: ON)
Beep
ON
Extension
OFF
Auto
MyCall
Disp
ON
Auto
RxCall
Disp
ON
