SPECIFICATIONS AND OPTIONS
New2001
16
■ Specifications
DD
GENERAL
• Frequency coverage : 1240.000–1300.000 MHz
• Type of emission : FM, GMSK
(Digital)
• Transmission speed (theoretical value):
Data 128 kbps
Digital voice 4.8 kbps
• Codec : AMBE (2.4 kbps)
• Number of memory channels:
105
(incl. 2 scan edges and 3 calls)
• Frequency resolution : 5, 6.25, 10, 12.5, 20, 25, 50,
100 kHz
• Operating temperature range:
–10°C to +60°C; +14˚F to +140˚F
• Frequency stability : ±2.5 ppm (–10˚C to +60°C)
• Power supply requirement: 13.8 V DC ±15%
• Current drain
(at 13.8 V DC; approx.)
:
Transmit at 10 W Less than 7 A
Receive max. audio Less than 1.5 A
• Antenna connector : Type-N
(50 Ω)
• Dimensions (proj. not included):
Main Unit 141(W) × 40(H) × 165.8(D) mm
5
9
⁄16(W)×1
9
⁄16(H)×6
17
⁄32(D) in
Remote controller
(RC-24)
150(W) × 50(H) × 49.5(D) mm
5
29
⁄32(W)×1
31
⁄32(H)×1
15
⁄16(D) in
• Weight
(approx.) :
Main unit 1.2 kg; 2 lb 10 oz
Remote controller 220 g; 7.7 oz
DD
TRANSMITTER
• Modulation system :
FM Variable reactance frequency
modulation
Digital Quadrature modulation
• Output power : 10/1 W
• Max. frequency deviation : ±5.0 kHz (FM)
• Spurious emissions : Less than –50 dB
• Microphone connector : 8-pin modular jack
(600 Ω)
DD
RECEIVER
• Receive system :
FM, Digital voice Triple-conversion superhetero-
dyne
Data Double-conversion super-
heterodyne
• Intermediate frequencies :
FM, Digital voice 1st: 243.95 MHz,
2nd: 31.05 MHz,
3rd: 450 kHz
Data 1st: 243.95 MHz,
2nd: 10.7 MHz
• Sensitivity
(FM: at 12 dB SINAD/Digital: at BER 1×10
–2
):
FM Less than 0.18 µV
Digital voice Less than 0.35 µV
Data Less then 1.58 µV
• Squelch sensitivity
(threshold):
Less than 0.18 µV (FM only)
