Icom ID-1 [33/124] Driver installation
![Icom ID-1 [33/124] Driver installation](/views2/1074124/page33/bg21.png)
26
3
DRIVER INSTALLATION
New2001
3
oSelect “Search for a suitable driver for my device (recom-
mended),” then click [Next>].
!0Select “CD-ROM drives,” then click [Next>].
Click
Select
Click
Select
ID-1_ENG_2.qxd 04.9.22 9:29 Page 26 (1,1)
