BASIC OPERATION
N Call channel programming
The Call channel is used to select Channel 9 (default); how-
ever, you can program the Call channel with your most often-
used channels in each channel group for quick recall.
q
While holding down [H/L], push ;#(78s$5!,s5)#= sev-
eral times to select the desired channel group (U.S.A., Inter-
national or Canada) to be programmed.
w Hold down ;s= for 1 second to select the Call channel
of the selected channel group.
shCALL” and Call channel number appear.
e Hold down ;s= again for
3 seconds (until a long beep
changes to 2 short beeps)
to enter the Call channel
programming mode.
s#HANNELNUMBERSTARTSBLINK-
ing.
r Rotate [DIAL] to select the
desired channel.
t Push ;s= to program the
displayed channel as the
Call channel.
s0USH[CLR] to cancel.
s4HE CHANNEL NUMBER STOPS
blinking.
N Channel comments
Each channel can be labeled with a unique alphanumeric ID
of up to 10 characters.
Capital letters, small letters, 0 to 9, some symbols (- . /)
and space can be used.
q Select the desired channel.
s#ANCEL$UALWATCH4RIWATCHOR3CANlRST
w While holding down [H/L],
push ;s= to edit the chan-
nel comment.
s!CURSORANDTHElRSTCHARACTER
start blinking alternately.
e Rotate [DIAL] to select the
desired character.
s0USH;s= to move the cursor forward, or ;#(78s$5!,s5
I/C] to move it backward.
r Repeat step e to input all characters.
s0USH[CLR] to cancel and exit the mode.
t Push ;$)!,s%.4%2= to input and set the comment.
s4HECURSORANDTHECHARACTERSTOPBLINKING
y Repeat steps q to t to program other channel com-
ments, if desired.
25W INT CALL
TAG
34°34.506N
123°23.236W
UTC 12:00 CALLING
25W INT CALL
DUP
34°34.506N
123°23.236W
UTC 12:00 INTL
25W INT
34°34.506N
123°23.236W
UTC 12:00PLEASURE__
