69
11
SPECIFICATIONS AND OPTIONS
N Options
s-" FLUSH MOUNT KIT
For mounting the transceiver to a panel.
s(-
COMMANDMICII™
External microphone-type controller. Provides optional
intercom operation. 6 m (20 feet) microphone cable and
mounting base included. Black and white colors are avail-
able.
Do not connect the HM-157 to the OPC-1541.
s(-
COMMANDMICIII™
External microphone-type controller. Provides optional
intercom operation. 6 m (20 feet) microphone cable and
mounting base included. Black and white colors are avail-
able.
Do not connect the HM-162 to the OPC-999.
s(-
HAND MICROPHONE
Equipped with [Y]/[Z] (channel up/down,) [HI/LO] and
[PTT] keys, a speaker and microphone.
s/0#
MICROPHONE EXTENSION CABLE
6 m (20 feet) microphone extension cable for optional HM-
157
COMMANDMICII™. Up to 2 OPC-999 can be connected.
(18 m; 60 feet maximum)
s/0#
MICROPHONE EXTENSION CABLE
6 m (20 feet) microphone extension cable for optional
HM-162
COMMANDMICIII™. Up to 2 OPC-1541 can be con-
nected. (18 m; 60 feet maximum)
s/0#
MICROPHONE CONNECTION CABLE
6 m (20 feet) microphone connection cable for the supplied
microphone (HM-126).
s54
VOICE SCRAMBLER UNIT
Ensures private communications. 32 codes are available.
Not available in some countries.
Approved Icom optional equipment is designed for optimal
performance when used with an Icom transceiver.
Icom is not responsible for the destruction or damage to an
Icom transceiver in the event the Icom transceiver is used
with equipment that is not manufactured or approved by Icom.
