49
7
OTHER FUNCTIONS
s7HILEINTHE)NTERCOMMODETHETRANSCEIVERSTRANSMIT
and receive functions are interrupted. If the transceiver is
in the transmit mode, the Intercom function is not avail-
able.
s7HENA$3##ALLISRECEIVEDTHE)NTERCOMMODEISAU-
tomatically cancelled. The received call type is displayed
on the LCD. (p. 35)
s7HENA78ALERTISRECEIVEDhWX ALERT” blinks and a
beep sounds. The WX alert sounds after exiting from the
Intercom mode.
N RX Speaker function
The IC-M504A has an RX Speaker function. When this func-
tion is turned ON, the received audio can be heard on the
deck or tower through a hailer speaker.
Connect a hailer speaker as described on page 56.
q Hold down
;(!),s28 ]
for 1 second to enter the RX
Speaker mode.
shRX ” appears.
25W INT
RX
TAG
RX
15
<ENT˘OK> CALLING
w Rotate [DIAL] to adjust the audio output level, then push
;$)!,s%.4%2=.
e
To return to normal operating mode, hold down ;(!),s28 ]
for 1 second.
shRX ” disappears.
To adjust the audio output level in the RX Speaker mode,
while holding down
;(!),s28 ]
, rotate [DIAL]. After ad-
justing, push ;$)!,s%.4%2=.
s2OTATE[DIAL] within 1 second after holding down
;(!),s28 ]
.
Otherwise the transceiver returns to the normal operation
mode.
