Cut here
HM-126/
HM-157
HM-162
Unit: mm (inch)
24 to 27 (d)
(
15
⁄16 to 1
1
⁄16)
2 (
3
⁄32)
165 (6
1
⁄2)
110 (4
11
⁄32)
146 (5
3
⁄4)
92.4 (3
5
⁄8)
2 (
3
⁄32)
29.5 to 31.5 (d)
(1
5
⁄32 to 1
1
⁄4)
R12 (Max.)
MB-75
71
13
TEMPLATE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
