DSC OPERATION
N DSC address ID
A total of 100 DSC address IDs can be programmed and
named with up to 10 characters.
D Programming Individual ID
q Enter “
Add:INDV ID
” in the DSC Set up menu.
eDSC Menuf ¶ eSet upf ¶ e
Add:INDV ID
f
(Push [MENU])
(Rotate [DIAL], then push ;$)!,s%.4%2=.)
w Rotate [DIAL]
to input
the individual ID and ID name.
s0USH;s= to move the cursor forward, or ;#(78s$5!,s5
I/C] to move it backward.
s0USH[CLR] to cancel and return to the DSC Set up menu.
s
“Full ID” appears when 100 DSC address IDs are already set.
s!FTERINPUTTINGTHEDIGITCODEPUSH;$)!,s%.4%2= or ;s= to
edit the ID name.
The first digit is specified as ‘0’ for a Group ID.
The first two digits are ‘0’ for any Coast station ID.
--DSC Menu--
Add:Individual ID
Input 9 digits
_________
Input name
_________
<CLR
˘
Exit / ENT
˘
OK>
e After inputting the ID name, push ;$)!,s%.4%2= to program.
r Push [CLR], or rotate [DIAL] to select “Exit” then push
;$)!,s%.4%2=, to return to the DSC menu.
s2EPEATSTEPr again to return to the normal operating mode.
D Deleting Individual ID
q Enter “
DEL:INDV ID
” in the DSC Set up menu.
eDSC Menuf ¶ eSet upf ¶ e
DEL:INDV ID
f
(Push [MENU])
(Rotate [DIAL], then push ;$)!,s%.4%2=.)
s7HENNOADDRESS)$ISPROGRAMMEDh
No ID
” is displayed. In
this case, push [CLR] to exit.
w Rotate [DIAL] to select the desired ID name to delete.
--DSC Menu--
Select ID
John
Paul
˘George
Michael
<CLR
˘
Exit / ENT
˘
OK>
e Push ;$)!,s%.4%2= to delete the selected individual ID
and return to the DSC Set up menu.
r Push [CLR], or rotate [DIAL] to select “Exit” then push
;$)!,s%.4%2=, to return to the DSC menu.
s2EPEATSTEPr again to return to the normal operating mode.
