CONNECTIONS AND MAINTENANCE
50 (d) mm; 1
31
⁄32˝
23 (d) mm;
29
⁄32˝
24 to 27 (d) mm
(
15
⁄16 to 1
1
⁄16˝)
5 mm;
3
⁄16˝
Gasket
Mounting base
Cap
Nut
2 mm;
3
⁄32˝
D HM-126/HM-157
