PCB Layout ESiEN02–01A
1–146 Part 1 – System Outline
3
11
4
5
8.2 Outdoor Units: PCB Numbers and Types
No. and types The table below contains the PCB numbers and types of the outdoor units.
Outdoor unit PCB 1 PCB 2 PCB 3
R35GZ7V11 — — —
R45GZ7V11
R45GZ7W11
R60GZ7W1
MA56GZ7W11 3SW00942-1
(type L)
2P068330-1
(type H)
3SA42153-1
(type K)
MA90GZ7W11 2PB38042-21
(type J)
3SW00942-1
(type L)
2PB32067-3
(type I)
RP71B7V1 3SW00943-1
(type M)
4SW00962-1 (type N) —
RP71B7W1 4SW00954-1 (type N)
RP71B7T1
RP100B7V1 4SW00963-1 (type N)
RP100B7W1 4SW00955-1 (type N)
RP100B7T1
RP125B7W1
RP125B7T1
RP200B7W1 2P050150-1
(type C)
4SW00958-1 (type N)
RP250B7W1 4SW00959-1 (type N)
RY35EAZ7V1 2P019606-1
(type B)
——
RY45EAZ7V1 2P019607-1
(type B)
RYP71B7V1 3SW00943-1
(type M)
4SW00964-1 (type N) —
RYP71B7W1 4SW00956-1 (type N)
RYP100B7V1 4SW00965-1 (type N)
RYP100B7W1 4SW00957-1 (type N)
RYP125B7W1
RYP200B7W1 2P050150-1
(type C)
3SW00943-1
(type M)
4SW00960-1
(type N)
RYP250B7W1
