Specifications ESiEN02–01A
1–68 Part 1 – System Outline
3
11
4
5
3.12 FUYP
Technical
specifications
The table below contains the technical specifications.
Electrical
specifications
The table below contains the electrical specifications.
Specification FUYP71BV17 FUYP100BV17 FUYP125BV17
Heat exchanger Length 2101 mm
Rows x stages x fin pitch 3 x 6 x 1.8 mm 3 x 8 x 1.8 mm
No. of passes 8 12
Face area
0.265 m
2
0.353 m
2
Tube type N-hiX tubes
Fin type Cross fin coil (multi louvre fins)
Empty tube hole 0 4 0
Fan Nominal air flow (cooling)
H: 19 m
3
/min
L: 14 m
3
/min
H: 29 m
3
/min
L: 21 m
3
/min
H: 32 m
3
/min
L: 23 m
3
/min
Nominal air flow (heating)
H: 19 m
3
/min
L: 14 m
3
/min
H: 29 m
3
/min
L: 21 m
3
/min
H: 32 m
3
/min
L: 23 m
3
/min
Fan motor model QTS48A10M QTS50B15M
Fan speed 2 steps
Fan type Turbo fan
Refrigerant circuit Type R407C
Safety and functional devices See page 1–91 and 3–14
Air filter Resin net (with mold resistant)
Insulation Heat Heat resistant foamed polyethylene
Regular foamed polyethylene
Weight 25 kg 31 kg
Specification FUYP71BV17 FUYP100BV17 FUYP125BV17
Unit Phase 1~
Voltage 230 V
Frequency 50 Hz
Fan motor Phase 1~
Voltage 230 V
Power consumption Cooling: 180 W
Heating: 160 W
Cooling: 289 W
Heating: 269 W
FLA (Full Load Amps) 0.6 A 1.0 A
No. of motors x output 1 x 45 W 1 x 90 W
