Specifications ESiEN02–01A
1–66 Part 1 – System Outline
3
11
4
5
3.10 FDYP
Technical
specifications
The table below contains the technical specifications.
Electrical
specifications
The table below contains the electrical specifications.
Specification FDYP125B7V1 FDYP200B7V1 FDYP250B7V1
Heat exchanger Rows x stages x fin pitch 3 x 14 x 1.75 mm 3 x 24 x 3 mm
Face area
0.338 m
2
0.634 m
2
Tube type Hi-XA
Fin type MLH7 fin hydrophilia Non symm. fin
Fan Nominal air flow (cooling)
43 m
3
/min 69 m
3
/min 89 m
3
/min
Fan motor model DPA216-178NB DPC241-241NB
Fan speed 3 steps 2 steps
Drive Direct drive
Static external pressure (50/60
Hz)
0-150 Pa 0-250 Pa
Refrigerant circuit Type R407C
Safety and functional devices See page 1–91 and 3–14
Air filter Filter class Eurovent 4/5 (EU2), EN 779 5G2)
Max. temperature 100°C
Cleaning Hot water 30-40°C or compressed air
Temperature control Computerized control
Insulation Sound absorbing Flame and heat resistant foamed felt
Weight 59 kg 90 kg 92 kg
Specification FDYP125B7V1 FDYP200B7V1 FDYP250B7V1
Unit Phase 1~
Voltage 230 V
Frequency 50 Hz
Fan motor No. of motors x output 500 W 650 W 1000 W
