Troubleshooting ESiEN02–01A
3–14 Part 3 – Troubleshooting
3
1
3
4
5
1.8 Overview of the Indoor Safety Devices
Overview The table below contains an overview of the indoor safety devices.
Applicable unit
Thermal protector fan motor
Thermal fuse
fan motor
Fuse PCB
Abnormal Reset (automatic)
FH(Y)C(P) > 130 ± 5°C < 83 ± 20°C N.A. 5 A
FHYBP N.A. N.A. > 152°C
FH(Y)(P) > 130 ± 5°C < 83 ± 20°C N.A.
FUYP > 130 ± 5°C < 83 ± 20°C N.A.
FDYP N.A. N.A. > 160°C
FAYP > 130 ± 5°C < 83 ± 20°C N.A.
FH(Y)K(P) > 120 ± 5°C < 105°C N.A.
