Field settings ESiEN02–01A
4–16 Part 4 – Commissioning and Test Run
3
1
4
5
2.7 Setting the Filter Counter
Mode No. 10 or 20
First code No. 0
When the filter counter indication time is set to ON, set the second code No., according to the table
below
When there is a heavy contamination and a long life filter is installed, the setting hours for the units
FHYCP and FHYP are 1 250 h.
Fan speed OFF
when
thermostat OFF
When the cool/heat thermostat is OFF, you can stop the indoor unit fan by switching the setting to
“Fan OFF”. This setting is used as a countermeasure against odour, for example for barber shops and
restaurants.
Fan speed
changeover when
thermostat OFF
You can switch the fan speed to the set fan speed when the heating thermostat is OFF. This setting is
called “Set Fan Speed”.
Air flow direction
setting
Set the air flow direction of the indoor units as given in the table below. This setting is needed when
the optional air outlet blocking pad has been installed. The “Second code No” is factory set to “01”.
Second code No. Contamination
Filter specifications
Long life Standard Ultra long life
01 Light contamination 2 500 h 200 h 10 000 h
02 Heavy contamination 1 100 h 100 h 5 000 h
Mode No. First code No. Second code No. Setting
11 or 21 2
01 —
02 Fan OFF
Mode No. First code No. Second code No. Setting
12 or 22 3
01 LL fan speed
02 Set fan speed
Mode No First code No Second code No Setting
13 or 23 1
01 F: four-direction air flow
02 T: three-direction air flow
03 W: two direction air flow
