General Functionality ESiEN02–01A
2–8 Part 2 – Functional Description
3
1
2
4
5
1.5 Forced Operating Mode (Emergency Operation)
Applicable units The forced operating mode is applicable for the following units:
Purpose The table below describes the purpose of the forced operating mode.
Starting conditions You can operate the system manually by changing the emergency switch on the indoor and outdoor
PCB from “normal” to “emergency”. However, when in emergency operation, the equipment cannot
control the temperature.
Make sure to set both indoor and outdoor unit to emergency. See page 2–10.
Ending conditions You can end the emergency operation by changing the emergency switch back to “normal” while the
power is OFF.
Emergency
operation
The table below describes what happens when you change the emergency switch to “emergency”.
Model type For this unit, you can go to...
RY35-45E(A)Z7V1
■ Forced cooling mode
■ Capacity control
RP71-250B Forced cooling mode
RYP71-250B
■ Forced cooling mode
■ Forced heating mode
If... Then...
■ Remocon is malfunctioning, or
■ Indoor PCB is off line, or
■ Outdoor PCB is off line
Forced operating mode can be used to go to cooling or heat-
ing. In forced operating mode, the compressor is forced to
operate until the malfunctioning indoor or outdoor PCB is
back online.
Changing the emergency switch to
“emergency” for the...
Switches ON...
Indoor unit
■ Indoor fan
■ Drain pump
Outdoor unit
■ Compressor
■ Outdoor fan(s)
