ESiEN02–01A Specifications
Part 1 – System Outline 1–59
3
1
4
5
3.3 RP71
Technical
specifications
The table below contains the technical specifications.
Electrical
specifications
The table below contains the electrical specifications.
Specification RP71B7V1 RP71B7W1 RP71B7T1
Compressor Model x No. JT90FA-V1N x 1 JT90FA-YE x 1 JT90FA-T1 x 1
Type Hermetically sealed scroll type
Refrigerant oil type DAPHNE FVC68D
Oil charge 1200 cc
Heat exchanger Length 860 mm
Rows x stages x fin pitch 2 x 38 x 2.0 mm
No. of passes 6
Face area
0.719 m
2
Tube type Hi-XA
Fin type Non symm. waffle louvre
Empty tubeplate hole 0
No. of fans 1
Fan Nominal air flow (230V) cooling
51 m
3
/min
Fan motor model P47L11S
Fan speed 3 steps
Refrigerant circuit Type R407C
Charge 3.1 kg
Safety and functional devices See page 1–71 and 3–15
Heat insulation Both liquid and gas pipes
Weight 88 kg 85 kg
Specification RP71B7V1 RP71B7W1 RP71B7T1
Unit Phase 1N~ 3N~ 3~
Voltage 230 V 400 V 230 V
Frequency 50 Hz
No. of wire connections 3 wires for power supply
(including earth wire)
4 wires for connection
with indoor (including
earth wire)
5 wires for power supply
(including earth wire)
4 wires for connection
with indoor (including
earth wire)
4 wires for power supply
(including earth wire)
4 wires for connection
with indoor (including
earth wire)
Power supply intake Outdoor unit only
Compressor Phase 1~ 3~
Voltage 230 V 400 V 230 V
Starting method Direct
No. x motor output 1 x 2200 W
Fan motor Phase 1~
Voltage 230 V
No. of motors x output 1 x 80 W
