Specifications ESiEN02–01A
1–60 Part 1 – System Outline
3
11
4
5
3.4 RP100, RP125, RP200 and RP250
Technical
specifications
The table below contains the technical specifications.
Electrical
specifications
The table below contains the electrical specifications.
Specification RP100B7V1 RP100B7W1 RP100B7T1 RP125B7W1 RP125B7T1 RP200B7W1 RP250B7W1
Compressor Model x No. JT125FA-V1N x 1 JT125FA-YE x 1 JT125FA-T1 x 1 JT160FA-YE x 1 JT160FA-T1 x 1 JT236DA-YE x 2 JT300DA-YE x 2
Type Hermetically sealed scroll type
Crankcase heater — — — — — 50 W 72 W
Refrigerant oil type DAPHNE FVC68D
Speed — ————2900 rpm
Oil charge 1500 cc 4000 cc
Heat exchanger Length 860 mm 1790 mm
Rows x stages x fin pitch 2 x 54 x 2.0 mm 2 x 40 x 2.0 mm 2 x 50 x 2.0 mm
No. of passes 9 13 18 16
Face area
1.022 m
2
1.57 m
2
1.97 m
2
Tube type Hi-XA
Fin type Non symm. waffle louvre
Empty tubeplate hole 8 0
No. of fans 2
Fan Nominal air flow (230V)
cooling
94 m
3
/min 170 m
3
/min 175 m
3
/min
Fan motor model P47L11S x 2 P55J11F P55J11F
Fan speed 3 steps 1 step
Refrigerant circuit Type R407C
Charge 3.6 kg 3.9 kg 7.5 kg 9.2 kg
Safety and functional devices See page 1–71 and 3–15
Heat insulation Both liquid and gas pipes
Weight 103 kg 98 kg 100 kg 194 kg 206 kg
Specification RP100B7V1 RP100B7W1 RP100B7T1 RP125B7W1 RP125B7T1 RP200B7W1 RP250B7W1
Unit Phase 1~ 3N~ 3~ 3N~ 3~ 3N~
Voltage 230 V 400 V 230 V 400 V 230 V 400 V
Frequency 50 Hz
No. of wire connections 3 wires for
power supply
(including earth
wire)
4 wires for con-
nection with
indoor (includ-
ing earth wire)
5 wires for
power supply
(including earth
wire)
4 wires for con-
nection with
indoor (includ-
ing earth wire)
4 wires for
power supply
(including earth
wire)
4 wires for con-
nection with
indoor (includ-
ing earth wire)
5 wires for
power supply
(including earth
wire)
4 wires for con-
nection with
indoor (includ-
ing earth wire)
4 wires for
power supply
(including earth
wire)
4 wires for con-
nection with
indoor (includ-
ing earth wire)
5 wires for power supply (including
earth wire)
4 wires for connection with indoor
(including earth wire)
Nominal running current
(cooling)
—————14.4 A17.2 A
Max. running current — — — — — 17.9 A 27.5 A
Power supply intake Outdoor unit only ——
Compressor Phase 1~ 3~ ——
Voltage 230 V 400 V 230 V 400 V 230 V — —
No. x motor output 1 x 3000 W 1x 3750 W 2 x 5500 W 2 x 7500 W
Starting method Direct ——
Fan motor Phase 1~ ——
Voltage 230 V ——
No. of motors x output 80 + 85 W 230 + 190 W 230 + 140 W
