ESiEN02–01A Specifications
Part 1 – System Outline 1–63
3
1
4
5
3.7 FHC
Technical
specifications
The table below contains the technical specifications.
Electrical
specifications
The table below contains the electrical specifications.
Specification FHC35BZ7V1 FHC45BZ7V1 FHC60BZ7V1
Heat exchanger Rows x stages x fin pitch 2 x 8 x 1.5 mm
Face area
0.331 m
2
Tube type Hi-XA
Fin type Cross fin coil
Fan Nominal air flow (cooling)
H: 14 m
3
/min
L: 10 m
3
/min
H: 15 m
3
/min
L: 11 m
3
/min
H: 18 m
3
/min
L: 14 m
3
/min
Fan motor model QTS56B14M
Fan speed 2 steps
Fan type Turbo fan
Drive Direct drive
Refrigerant circuit Type R407C
Safety and functional devices See page 1–91 and 3–14
Air filter Resin net (mold resistant)
Temperature control Computerized control
Insulation Heat Foamed polystyrene
Sound absorbing
Weight Unit: 23 kg
Decoration panel: 5 kg
Specification FHC35BZ7V1 FHC45BZ7V1 FHC60BZ7V1
Unit Phase 1~
Voltage 230 V
Frequency 50 Hz
Fan motor No. of motors x output 1 x 45 W
Power consumption 140 W 161 W
FLA (Full Load Amps) 0.6 A
