ESiEN02–01A Specifications
Part 1 – System Outline 1–65
3
1
4
5
3.9 FHYBP
Technical
specifications
The table below contains the technical specifications.
Electrical
specifications
The table below contains the electrical specifications.
Specification FHYBP35B7V1 FHYBP45B7V1 FHYBP60B7V1 FHYBP71B7V1 FHYBP100B7V1 FHYBP125B7V1
Heat exchanger Length 450 mm 750 mm 1150 mm
Rows x stages x fin pitch 3 x 14 x 1.75 mm
No. of passes 4 6 7 10 13
Face area
0.132 m
2
0.221 m
2
0.338 m
2
Tube type Hi-XA
Fin type Fin Rhombus type
Empty tube hole 4 0 14 0
No. of fans 1 2 3
Fan Nominal air flow (cooling)
H: 11.5 m
3
/min
L: 9 m
3
/min
H: 14 m
3
/min
L: 10 m
3
/min
H: 19 m
3
/min
L: 14 m
3
/min
H: 27 m
3
/min
L: 20 m
3
/min
H: 35 m
3
/min
L: 24 m
3
/min
Nominal air flow (heating)
H: 11.5 m
3
/min
L: 9 m
3
/min
H: 14 m
3
/min
L: 10 m
3
/min
H: 19 m
3
/min
L: 14 m
3
/min
H: 27 m
3
/min
L: 20 m
3
/min
H: 35 m
3
/min
L: 24 m
3
/min
Fan speed 2 steps
Fan type Sirocco fan
Drive Direct drive
Static external pressure (50/60
Hz)
——H: 88
M: 49
L: 20
H: 88
M: 49
Refrigerant circuit Type R407C
Safety and functional devices See page 1–91 and 3–14
Insulation Heat Both liquid and gas pipes
Sound absorbing Flame and heat resistant foamed pol-
yethylene, regular foamed polyethyl-
ene and foamed PU
Foamed polyurethane
Weight 30 kg 31 kg 41 kg 51 kg 52 kg
Specification FHYBP35B7V1 FHYBP45B7V1 FHYBP60B7V1 FHYBP71B7V1 FHYBP100B7V1 FHYBP125B7V1
Unit Phase 1~
Voltage 230 V
Frequency 50 Hz
Recommended fuses 16 A 20 A — — — —
Fan motor Phase 1~
Voltage 230 V
Nominal running current 0.5 A 0.7 A 0.9 A 1.0 A 1.4 A
No. of motors x output 1 x 65 W 1 x 85 W 1 x 125 W 1 x 135 W 1 x 225 W
Power consumption 65 W 85 W 125 W 135 W 225 W
