General Outline: Indoor Units ESiEN02–01A
1–50 Part 1 – System Outline
3
11
4
5
2.15 FAYP71BV1 and FAYP100BV1
Outlook and
dimensions
The illustration below shows the outlook, the dimensions and the installation and service space of the
unit (mm).
Direction for air filter
draw out
50 or more
Piping
direction
50 or more
50 or more
Mounting hole for
installation plate
Detail A
± 450
± 580
± 600
Name plate
250 or more
