Daikin FH35BZV1 [248/397] Outdoor safety device low pressure switch
![Daikin RP125B7T1 [248/397] Outdoor safety device low pressure switch](/views2/1697477/page248/bgf8.png)
Troubleshooting ESiEN02–01A
3–20 Part 3 – Troubleshooting
3
1
3
4
5
1.14 Outdoor Safety Device: Low-Pressure Switch
Low-pressure
switch
The table below describes the low-pressure switch.
Applicable
outdoor unit
Wiring
symbol
Location
safety
Settings Type
Abnormal Reset Reset
RP71B7V1
S1LP
Low-pres-
sure switch
located in
suction
pipe
< -0.3 bar > +0.5 bar Automatic
RYP71B7V1
RP71B7W1
RYP71B7W1
RP71B7T1
RP100B7V1
RYP100B7V1
RP100B7W1
RYP100B7W1
RP100B7T1
RP125B7W1
RYP125B7W1
RP125B7T1
RP200B7W1
RYP200B7W1
RP250B7W1
RYP250B7W1
